Product Summary

The B65555A is a High Performance Flat Panel/Crt Gui Controller.

Parametrics

B65555A absolute maximum ratings: (1)VCC, Supply voltage: 5V; (2)VI, input voltage: 5.5V; (3)TSTG, Storage temp: -40 to 125℃.

Features

B65555A features: (1)Video port manager for ZV port; (2)Set active display type; (3)save/restore video state; (4)PCVideo DLL plus tuner with DK board; (5)Setup memory for save/restore.

Diagrams

B65555A pin diagram
