DS80C320MNL+

DS80C320MNL+, High-Speed/Low-Power Microcontroller, DIP, -0.3V, 2.4V, Maxim Integrated Products

Rated 5 Rating 5 | reviews | Write a review

Price:: US $10.00~10.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $10.00~10.50

PartNumber:: DS80C320MNL+

Brand:: Maxim Integrated Products - Maxim | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Zhao's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-09-11

From Other Seller

Part Number:DS80C320MNL+
US $10.00 - 10.50
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
HCPL-7800A

US $2.50 - 4.10 / Piece
(0) Remove
Quantity:

piece

Product Summary

The DS80C320MNL+ is a High-Speed/Low-Power Microcontroller. The DS80C320MNL+ is fast 80C31/80C32-compatible microcontrollers. Wasted clock and memory cycles have been removed using a redesigned processor core. As a result, every 8051 instruction is executed between 1.5 and 3 times faster than the original for the same crystal speed. Typical applications see a speed improvement of 2.5 times using the same code and same crystal. The DS80C320MNL+ offers a maximum crystal rate of 33MHz, resulting in apparent execution speeds of 82.5MHz (approximately 2.5X). The DS80C320MNL+ is pin compatible with all three packages of the standard 80C32 and offer the same timer/counters, serial port, and I/O ports. In short, the devices are extremely familiar to 8051 users, but provide the speed of a 16-bit processor. The DS80C320MNL+ provides several extras in addition to greater speed. These include a second full hardware serial port, seven additional interrupts, programmable watchdog timer, power-fail interrupt and reset. The device also provides dual data pointers (DPTRs) to speed block data memory moves. It can also adjust the speed of off-chip data memory access to between two and nine machine cycles for flexibility in selecting memory and peripherals.

Parametrics

DS80C320MNL+ absolute maximum ratings: (1)Voltage Range on Any Pin Relative to Ground: -0.3V to (VCC + 0.5V); (2)Voltage Range on VCC Relative to Ground: -0.3V to +6.0V; (3)Operating Temperature Range: -40℃ to +85℃; (4)Storage Temperature Range: -55℃ to +125℃; (5)Soldering Temperature: See IPC/JEDEC J-STD-020A Specification.

Features

DS80C320MNL+ features: (1)Two Full-Duplex Hardware Serial Ports; (2)13 Total Interrupt Sources with Six External; (3)Available in 40-Pin DIP, 44-Pin PLCC, and 44-Pin TQFP.
