Product Summary

The HCPL-063L-500E is a high speed LVTTL compatible 3.3V optocoupler. Its applications include isolated line receiver, computer-peripheral interfaces, digital isolation for A/D, D/A conversion, switching power supply, instrument input/output isolation, ground loop elimination, pulse transformer replacement, field buses.

Parametrics

HCPL-063L-500E absolute maximum ratings: (1)Storage temperature, TS: 125℃; (2)Operating temperature, TA: 85℃; (3)Average forward input current, IF: 15mA; (4)Reverse input voltage, VR: 5V; (5)Input power dissipation, PI: 40mW; (6)Supply voltage, VCC: 7V; (7)Enable input voltage, VE: VCC +0.5V; (8)Enable input current, IE: 5mA; (9)Output collector current, IO: 50mA; (10)Output collector voltage, VO: 7V; (11)Output collector power dissipation: 60mW.

Features

HCPL-063L-500E features: (1)3.3V/5V dual supply voltages; (2)Low power consumption; (3)15kV/μs minimum common mode rejection (CMR) at VCM=1000V; (4)High speed: 15MBd typical; (5)Low input current capability: 5mA; (6)Guaranteed AC and DC performance over temperature: -40 to +85℃; (7)Available in 8-pin DIP, SOIC-8; (8)Strobable outputs; (9)Safety approval: UL, CSA.

Diagrams

HCPL-063L-500E functional diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
HCPL-063L-500E
HCPL-063L-500E

Avago Technologies

High Speed Optocouplers 15MBd 2Ch 5mA

Data Sheet

0-1: $3.34
1-25: $2.73
25-100: $2.42
100-250: $2.18
