Product Summary
The LT1363CS8#TR is a high speed, very high slew rate operational amplifier with excellent DC performance. The LT1363CS8#TR features reduced supply current, lower input offset voltage, lower input bias current and higher DC gain than devices with comparable bandwidth. Its applications include wideband amplifiers, buffers, active filters, video and RF amplification, cable drivers, data acquisition systems.
Parametrics
LT1363CS8#TR absolute maximum ratings: (1)Total supply voltage: 36V; (2)Differential input voltage: ±10V; (3)Input voltage: ±Vs; (4)Output short-circuit duration: indefinite; (5)Operating temperature range: -40 to 85℃; (6)Specified temperature range: -40 to 85℃; (7)Maximum junction temperature: 150℃; (8)Storage temperature range: -65 to 150℃; (9)Lead temperature: 300℃.
Features
LT1363CS8#TR features: (1)70MHz gain bandwidth; (2)1000V/μs slew rate; (3)7.5mA maximum supply current; (4)Unity-gain stable; (5)1.5mV maximum input offset voltage; (6)2μA maximum input bias current; (7)
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LT1363CS8#TR |
|
IC OPAMP 70MHZ HI SPEED LP 8SOIC |
Data Sheet |
|
|
||||||
|
LT1363CS8#TRPBF |
|
IC OP-AMP HISPD 70MHZ SNGL 8SOIC |
Data Sheet |
|
|
||||||
