Product Summary
The TLV2361CDBVRG4 is a high-performance low-voltage operational amplifier. The TLV2361CDBVRG4 is high-performance dual operational amplifiers built using an original Texas Instruments bipolar process. The TLV2361CDBVRG4 can be operated at a very low supply voltage (±1 V), while maintaining a wide output swing. The TLV2361CDBVRG4 offers a dramatically improved dynamic range of signal conditioning in low-voltage systems. The TLV2361CDBVRG4 also provides higher performance than other general-purpose operational amplifiers by combining higher unity-gain bandwidth and faster slew rate. With their low distortion and low-noise performance, these devices are well suited for audio applications.
Parametrics
TLV2361CDBVRG4 absolute maximum ratings: (1)Supply voltage, VCC+ (see Note 1): 3.5 V; (2)Supply voltage, VCC. (see Note 1): 3.5 V; (3)Differential input voltage, VID (see Note 2): ±3.5 V; (4)Input voltage, VI (any input) (see Notes 1 and 3): VCC±; (5)Output voltage, VO : ±3.5 V; (6)Output current, IO : 20 mA; (7)Duration of short-circuit current at (or below) 25℃ (output shorted to GND): Unlimited; (8)Package thermal impedance, θJA (see Notes 4 and 5): 97℃/W; (9)Operating virtual junction temperature: 150℃; (10)Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds : 260℃; (11)Storage temperature range: 65℃ to 150℃.
Features
TLV2361CDBVRG4 features: (1)Low Supply-Voltage Operation: VCC = ±1 V Min; (2)Wide Bandwidth: 7 MHz Typ at VCC± = ±2.5 V; (3)High Slew Rate: 3 V/μs Typ at VCC± = ±2.5 V; (4)Wide Output Voltage Swing: ±2.4 V Typ at VCC± = ±2.5 V, RL = 10 kΩ.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TLV2361CDBVRG4 |
Texas Instruments |
Operational Amplifiers - Op Amps Sgl Hi-Perf Lo-Vltg Op Amp |
Data Sheet |
|
|
|||||||||||||
