Product Summary

The PH5330 is an N-channel enhancement mode field-effect transistor. Its applications include DC to DC converter, computer motherboards, switch mode power supplies.

Parametrics

PH5330 absolute maximum ratings: (1)VDS, drain-source voltage: 30V; (2)VGS, gate-source voltage: ±20V; (3)ID, drain current: 50A; (4)IDM, peak drain current: 160A; (5)Ptot, total power dissipation: 39W; (6)Tstg, storage temperature: -55 to 150℃; (7)Tj, operating junction temperature: -55 to 150℃.

Features

PH5330 features: (1)Logic level compatible; (2)Low drive current; (3)High density mounting.

Diagrams

PH5330 diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
PH5330
PH5330

Other


Data Sheet

Negotiable
PH5330E,115
PH5330E,115

NXP Semiconductors

MOSFET N-CH TRENCH 30V

Data Sheet

Negotiable
