LT1112S8#PBF

LT1112 - Dual Low Power Precision, Picoamp Input Op Amps

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.10~1.30 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.10~1.30

PartNumber:: LT1112S8#PBF

Brand:: Linear Technology - Linear | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Zhao's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-10-18

From Other Seller

Part Number:LT1112S8#PBF
US $1.10 - 1.30
AT45DB161B-TU

US $1.00 - 2.00 / Piece
(0) Remove
MJ16018

US $1.80 - 2.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LT1112 dual and LT1114 quad op amps achieve a new standard in combining low cost and outstanding precision specifications.

The performance of the selected prime grades matches or exceeds competitive devices. In the design of the LT1112/ LT1114 however, particular emphasis has been placed on optimizing performance in the low cost plastic and SO packages. For example, the 75μV maximum offset voltage in these low cost packages is the lowest on any dual or quad non-chopper op amp.

The LT1112/LT1114 also provide a full set of matching specifications, facilitating their use in such matching dependent applications as two and three op amp instrumentation amplifiers.

Another set of specifications is furnished at ±1V supplies. This, combined with the low 320μA supply current per amplifier, allows the LT1112/LT1114 to be powered by two nearly discharged AA cells.

Protected by U.S. Patents 4,575,685; 4,775,884 and 4,837,496

Among them if you have any need quote or problem, please could you tell us.
E-mail: abel.huang911@gamil.com
MSN:abel.huang@hotmail.com

Features

Offset Voltage – Prime Grade: 60μV Max
Offset Voltage – Low Cost Grade
(Including Surface Mount Dual/Quad): 75μV Max
Offset Voltage Drift: 0.5μV/°C Max
Input Bias Current: 250pA Max
0.1Hz to 10Hz Noise: 0.3μVP-P, 2.2pAP-P
Supply Current per Amplifier: 400μA Max
CMRR: 120dB Min
Voltage Gain: 1 Million Min
Guaranteed Specs with ±1.0V Supplies
Guaranteed Matching Specifications
SO-8 Package – Standard Pinout
LT1114 in Narrow Surface Mount Package
