Product Summary
The LT1761ES5-BYP#TRPBF is a low noise LDO micropower regulator in TSOT-23. Its applications include cellular phones, pagers, battery-powered systems, frequency synthesizers.
Parametrics
LT1761ES5-BYP#TRPBF absolute maximum ratings: (1)IN pin voltage: ±20v; (2)OUT pin voltage: ±20V; (3)Input to output differential voltage: ±20V; (4)ADJ pin voltage: 7V; (5)Operating junction temperature range: -40 to 125℃; (6)Storage temperature range: -65 to 150℃; (7)Lead temperature: 300℃.
Features
LT1761ES5-BYP#TRPBF features: (1)Low noise: 20μVRMS; (2)Low quiescent current: 20μA; (3)Wide input voltage range: 1.8 to 20V; (4)Output current: 100mA; (5)Very low shutdown current: <0.1μA，
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LT1761ES5-BYP#TRPBF |
|
IC REG LDO ADJ .1A TSOT23-5 |
Data Sheet |
|
|
||||||||||
