LT1936EMS8E#TRPBF

LT1936 - 1.4A, 500kHz Step-Down Switching Regulator

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.00~2.40 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $2.00~2.40

PartNumber:: LT1936EMS8E#TRPBF

Brand:: Linear Technology - Linear | Pack: MSOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Zhao's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-10-18

From Other Seller

Part Number:LT1936EMS8E#TRPBF
US $2.00 - 2.40
ad7716ap

US $1.13 - 1.13 / Piece
(0) Remove
AT45DB161D-SU

US $1.50 - 3.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LT1936 is a current mode PWM step-down DC/DC converter with an internal 1.9A power switch, packaged in a tiny, thermally enhanced 8-lead MSOP. The wide input range of 3.6V to 36V makes the LT1936 suitable for regulating power from a wide variety of sources, including automotive batteries, 24V industrial supplies and unregulated wall adapters. Its high operating frequency allows the use of small, low cost inductors and ceramic capacitors, resulting in low, predictable output ripple.

Cycle-by-cycle current limit, frequency foldback and thermal shutdown provide protection against shorted outputs, and soft-start eliminates input current surge during startup. Transient response can be optimized by using external compensation components, or board space can be minimized by using internal compensation. The low current (<2μA) shutdown mode enables easy power management in battery-powered systems.

Among them if you have any need quote or problem, please could you tell us.
E-mail: abel.huang911@gamil.com
MSN:abel.huang@hotmail.com

Features

Wide Input Range: 3.6V to 36V
Short-Circuit Protected Over Full Input Range
1.9A Guaranteed Minimum Switch Current
5V at 1.4A from 10V to 36V Input
3.3V at 1.4A from 7V to 36V Input
5V at 1.2A from 6.3V to 36V Input
3.3V at 1.2A from 4.5V to 36V Input
Output Adjustable Down to 1.20V
500kHz Fixed Frequency Operation
Soft-Start
Uses Small Ceramic Capacitors
Internal or External Compensation
Low Shutdown Current: <2μA
Thermally Enhanced 8-Lead MSOP Package
