Product Summary

The LTC4151IMS#TRPBF is a high voltage I2C current voltage monitor. Its applications include telecom infrastructure, automotive, industrial and consumer.

Parametrics

LTC4151IMS#TRPBF absolute maximum ratings: (1)VIN voltage: -0.3 to 90V; (2)ADR1, ADR0 voltage: -0.3 to 90V; (3)ADIN, SHDN, SDAO voltage: -0.3 to 6V; (4)SCL, SDA, SDAI clamp current: 5mA; (5)Operating temperature range: -40 to 85℃; (6)Storage temperature range: -65 to 150℃; (7)Lead temperature: 300℃.

Features

LTC4151IMS#TRPBF features: (1)Wide operating voltage range: 7V to 80V; (2)12-Bit resolution for both current and voltages; (3)I2C interface; (4)Additional ADC input monitors an external voltage; (5)Continuous scan and snapshot modes; (6)Split SDA for optoisolation.

Diagrams

LTC4151IMS#TRPBF pin configuration

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
LTC4151IMS#TRPBF
LTC4151IMS#TRPBF


IC CURRENT MONITOR(12BIT) 10MSOP

Data Sheet

0-2500: $2.78
