Product Summary

The NCP1203P100G is a PWM current-mode controller for universal off-line supplies featuring standby and short circuit protection.

Parametrics

NCP1203P100G absolute maximum ratings: (1)Power supply voltage: 16V; (2)Power supply voltage on all other pins except 5,6,8: -0.3 to 10V; (3)Maximum junction temperature: 150℃; (4)Hysteresis in shutdown: 30℃; (5)Operating temperature range: -40 to 125℃; (6)ESD capability, machine: 200V.

Features

NCP1203P100G features: (1)High-voltage startup current source; (2)Auto-recovery internal output short-circuit protection; (3)Extremely low no-load standby power; (4)Internal leading edge blanking; (5)250mA peak current capability.

Diagrams

NCP1203P100G pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
NCP1203P100G
NCP1203P100G

ON Semiconductor

Current Mode PWM Controllers 100KHz Current Mode SMPS PWM

Data Sheet

0-1: $0.68
1-25: $0.58
25-100: $0.50
100-500: $0.35
