Product Summary
The 2MBI150SD-060-01 is an IGBT module. The applications of the 2MBI150SD-060-01 include High Power Switching, A.C. Motor Controls, D.C. Motor Controls, Uninterruptible Power Supply.
Parametrics
2MBI150SD-060-01 absolute maximum ratings: (1)Collector-Emitter Voltage VCES: 1200V; (2)Gate -Emitter Voltage VGES: ±20 V; (3)Continuous 25℃/ 80℃ IC: 200/150A; (4)Collector Current 1ms 25℃/ 80℃ IC PULSE: 400/300A; (5)Max. Power Dissipation PC: 1000W; (6)Operating Temperature Tj: +150℃; (7)Storage Temperature Tstg: -40 to +125℃.
Features
2MBI150SD-060-01 features: (1)NPT-Technology; (2)Square SC SOA at 10 x IC; (3)High Short Circuit Withstand-Capability; (4)Small Temperature Dependence of the Turn-Off Switching Loss; (5)Low Losses And Soft Switching.
