Product Summary
The CS51414GDR8 is a low voltage buck regulator with external bias or synchronization capability.
Parametrics
CS51414GDR8 absolute maximum ratings: (1)VIN: 40V; (2)BOOST: 40V; (3)BSW: 40V; (4)VC: 7V; (5)SHDNB: 7V; (6)SYNC: 7V; (7)BIAS: 7V.
Features
CS51414GDR8 features: (1)Switch frequency decrease of 4:1 in short circuit conditions reduces short circuit power dissipation; (2)2% error amp reference voltage tolerance; (3)Shutdown lead provides power-down option; (4)Thermal shutdown; (5)85μA quiescent current during power-down; (6)Sync function for parallel supply operation or noise minimization.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 CS51414GDR8 |
ON Semiconductor |
Switching Converters, Regulators & Controllers 1.5A Low Voltage |
Data Sheet |
Negotiable |
|
||||||||||||
|
CS51414GDR8G |
ON Semiconductor |
Switching Converters, Regulators & Controllers 1.5A Low Voltage Buck |
Data Sheet |
|
|
||||||||||||
