LT1490CS8#TRPBF

LT1490CS8#TRPBF, Op Amps, SOP, 20mA, 3V, Linear Technology

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.40~1.60 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.40~1.60

PartNumber:: LT1490CS8#TRPBF

Brand:: Linear Technology - Linear | Pack: SOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Zhao's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-09-17

From Other Seller

Part Number:LT1490CS8#TRPBF
US $1.40 - 1.60
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LT1490CS8#TRPBF is an Op Amps. The LT1490CS8#TRPBF operates on all single and split supplies with a total voltage of 2V to 44V drawing only 40mA of quiescent current per amplifier. The LT1490CS8#TRPBF is reverse supply protected; they draw no current for reverse supply up to 18V. The input range of the LT1490CS8#TRPBF includes both supplies and the output swings to both supplies. Unlike most micropower op amps, the LT1490CS8#TRPBF can drive heavy loads; their rail-to-rail outputs drive 20mA. The LT1490CS8#TRPBF is unity-gain stable and drive all capacitive loads up to 10,000pF when optional 0.22mF and 150W compensation is used. The applications of the LT1490CS8#TRPBF include Supply Current Sensing, Battery Monitoring, Micropower Active Filters and 4mA to 20mA Transmitters.

Parametrics

LT1490CS8#TRPBF absolute maximum ratings: (1)Total Supply Voltage (V+ to V–): 44V; (2)Input Differential Voltage: 44V; (3)Input Current: ±25mA; (4)Output Short-Circuit Duration (Note 1): Continuous; (5)Operating Temperature Range: – 40℃ to 85℃; (6)Junction Temperature: 150℃; (7)Specified Temperature Range (Note 2): – 40℃ to 85℃; (8)Storage Temperature Range: –65℃ to 150℃; (9)Lead Temperature (Soldering, 10 sec): 300℃.

Features

LT1490CS8#TRPBF features: (1)Rail-to-Rail Input and Output; (2)Single Supply Input Range: –0.4V to 44V; (3)Micropower: 50mA/Amplifier Max; (4)Specified on 3V, 5V and ±15V Supplies; (5)High Output Current: 20mA; (6)Output Drives 10,000pF with Output Compensation; (7)Reverse Battery Protection to 18V; (8)No Supply Sequencing Problems; (9)High Voltage Gain: 1500V/mV; (10)High CMRR: 98dB; (11)No Phase Reversal; (12)Gain Bandwidth Product: 200kHz.
