LT3493EDCB#TRPBF

LT3493EDCB#TRPBF, Step-Down Switching Regulator, SOT, 1.2A, 3.6V, Linear Technology

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~1.30 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~1.30

PartNumber:: LT3493EDCB#TRPBF

Brand:: Linear Technology - Linear | Pack: SOT | D/C: 07+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Zhao's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-10-07

From Other Seller

Part Number:LT3493EDCB#TRPBF
US $1.00 - 1.30
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LT3493EDCB#TRPBF is a Step-Down Switching Regulator. The LT3493EDCB#TRPBF is a current mode PWM step-down DC/DC converter with an internal 1.75A power switch. The wide operating input range of 3.6V to 36V (40V maximum) makes the LT3493EDCB#TRPBF ideal for regulating power from a wide variety of sources, including unregulated wall transformers, 24V industrial supplies and automotive batteries. Its high operating frequency allows the use of tiny, low cost inductors and ceramic capacitors, resulting in low, predictable output ripple. Cycle-by-cycle current limit provides protection against shorted outputs and soft-start eliminates input current surge during start-up. The low current (<2μA) shutdown mode provides output disconnect, enabling easy power management in battery-powered systems. The applications of the LT3493EDCB#TRPBF include Automotive Battery Regulation, Industrial Control Supplies, Wall Transformer Regulation, Distributed Supply Regulation and Battery-Powered Equipment.

Parametrics

LT3493EDCB#TRPBF absolute maximum ratings: (1)Input Voltage (VIN): 40V; (2)BOOST Pin Voltage: 50V; (3)BOOST Pin Above SW Pin: 25V; (4)SHDN Pin: 40V; (5)FB Voltage: 6V; (6)Operating Temperature Range (Note 2): –40℃ to 85℃; (7)Maximum Junction Temperature: 125℃; (8)Storage Temperature Range: –65℃ to 150℃.

Features

LT3493EDCB#TRPBF features: (1)Wide Input Range: 3.6V to 36V Operating, 40V Maximum; (2)1.2A Output Current; (3)Fixed Frequency Operation: 750kHz; (4)Output Adjustable Down to 780mV; (5)Short-Circuit Robust; (6)Uses Tiny Capacitors and Inductors; (7)Soft-Start; (8)Internally Compensated; (9)Low Shutdown Current: <2μA; (10)Low VCESAT Switch: 330mV at 1A; (11)Thermally Enhanced, Low Profile DFN Package.
