The ST72C104G1M6 is an Analog -to- Digital Converter.

Parametrics

ST72C104G1M6 absolute maximum ratings: (1)Total current into VDD power lines (source) 3): 80mA; (2)IVSS Total current out of VSS ground lines (sink) 3): 80mA; (3)Output current sunk by any standard I/O and control pin: 25mA; (4)Output current sunk by any high sink I/O pin: 50mA; (5)Output current source by any I/Os and control pin: - 25mA; (6)Injected current on ISPSEL pin: ± 5mA; (7)Injected current on RESET pin: ± 5mA; (8)Injected current on OSC1 and OSC2 pins: ± 5mA; (9)Injected current on any other pin: ± 5mA; (10)Total injected current (sum of all I/O and control pins: ± 20mA.

Features

ST72C104G1M6 features: (1)Memories 4K or 8K bytes Program memory (ROM and single voltage FLASH) with read-out protection and in-situ programming (remote ISP); (2)256 bytes RAM; (3)Clock, Reset and Supply Management Enhanced reset system Enhanced low voltage supply supervisor with 3 programmable levels; (4)Clock sources: crystal/ceramic resonator oscillators or RC oscillators, external clock, backup Clock Security System; (5)Clock-out capability; (6)3 Power Saving Modes: Halt, Wait and Slow; (7)Interrupt Management 7 interrupt vectors plus TRAP and RESET; (8)22 external interrupt lines (on 2 vectors); (9)22 I/O Ports 22 multifunctional bidirectional I/O lines; (10)14 alternate function lines; (11)8 high sink outputs.
