Product Summary
The LTC2981AIGN-1#PBF is an I2C Programmable Precision Reference with EEPROM. It combines an ultralow drift reference, a precise low drift 8-bit adjustment DAC, a low drift, low noise buffer and internal EEPROM. While external pins or internal register bits set the central output voltage, an 8-bit I2C DAC adjusts this mid-scale output with a selectable, relative ±1% or ±10% range. Both mid-scale output voltage level and DAC settings can be stored in EEPROM and restored upon power-up. The LTC2981BCGN#PBF accepts input voltages between 2.9V and 15V. Both references offer extremely good accuracy over temperature with 10ppm/℃ drift. The applications of the LTC2981BCGN#PBF include Precision Reference, Instrumentation and Process Control, Data Acquisition Systems, Test Equipment, Power Supply Margining, Medical Equipment.
Parametrics
LTC2981BCGN#PBF absolute maximum ratings: (1)Two Adjustment Ranges: ±1% or ±10%; (2)Wide Input Voltage Range: 2.9V to 15V; (3)Low Dropout: 400mV; (4)0.1Hz to 10Hz Noise: 10ppmP-P; (5)Load Regulation: 20ppm/mA with ±5mA Drive; (6)400kHz I2C Interface (SMBus Compatible).
Features
LTC2981BCGN#PBF features: (1)High Accuracy:±0.05%; (2)Drift:10ppm/℃; (3)16 Output Voltage Levels (LTC2981); (4)8-Bit Relative Adjustment DAC; (5)Internal EEPROM; (6)16-Pin Plastic SSOP Package.
Diagrams
 |
