Product Summary
The SAA7173HL/V101 is an Analog TV video and stereo decoder. The SAA7173HL/V101 decodes to a wide variety of computing and consumer products. Its 100% pin compatibility with the Philips SAA7174 decoder enables efficient reuse of SAA7174 designs.The SAA7173HL/V101 is targeted for products in North American and Japanese markets such as desktop and portable PCs, personal video recorders (with time shifting), hybrid (analog/digital) TVs and cable, terrestrial, and satellite set-top boxes, USB/1394 video dongles, DVD recorders, and more.
Parametrics
SAA7173HL/V101 absolute maximum ratings: (1)Supply voltage: 3.3V; (2)Power consumption: 1.35W; (3)temperature range: 0 to 70℃.
Features
SAA7173HL/V101 features: (1)Fully automatic detection and decoding of worldwide analogTV video formats: PAL, NTSC, and SECAM; (2)Automatic standard detection and decoding of TV stereo formats:; (3)BTSC (with dbx noise reduction), SAP, EIAJ, and FM radio; (4)Supports simultaneous stereo decoding and adaptive 3D comb filtering to enhance picture quality; (5)Certified three-level Macrovision detection circuitry; (6)Advanced audio feature processing: volume, balance, bass, treble, automatic volume leveling (AVL), and Philips Incredible Sound; (7)Captures raw VBI data (for Closed Captioning,Teletext, etc.); (8)Superior subpixel-accurate horizontal and vertical scaling; (9)Outputs digital I2S audio and ITU-656 video.
Diagrams
 |
