Product Summary
The MAX3223EEAP+T is an ESD-Protected RS-232 transceiver with autoshutdown. Its applications include notebook, subnotebook, and palmtop computers, cellular phones, battery-powered equipment, handset equipment, peripherals, printers.
Parametrics
MAX3223EEAP+T absolute maximum ratings: (1)VCC to GND: -0.3 to 6V; (2)Input voltage: ±25V; (3)Continuous power dissipation: 571mW; (4)Operating temperature range: -40 to 85℃; (5)Storage temperature range: -65 to 160℃; (6)Lead temperature: 300℃; (7)Soldering temperature: 260℃.
Features
MAX3223EEAP+T characteristics: (1)Supply current, autoshotdown: 10μA; (2)Supply current, shutdown: 10μA; (3)Supply current, autoshutdown disabled: 1mA; (4)Input logic threshold low: 0.8V; (5)Transmitter input hysteresis: 0.5V.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 MAX3223EEAP+T |
Maxim Integrated Products |
RS-232 Interface IC 3-5.5V 1Mbps Transceiver |
Data Sheet |
|
|
||||||||
 |
MAX3223EEAP+TG071 |
Maxim Integrated Products |
RS-232 Interface IC 3-5.5V 1Mbps Transceiver |
Data Sheet |
|
|
||||||||
