Product Summary
The LTC3603 is a high efficiency, monolithic synchronous step-down DC/DC converter utilizing a constant-frequency, current mode architecture. It operates from an input voltage range of 4.5V to 15V and provides an adjustable regulated output voltage from 0.6V to 14.5V while delivering up to 2.5A of output current. The internal synchronous power switch with 45mΩ on-resistance increases efficiency and eliminates the need for an external Schottky diode. The switching frequency can either be set by an external resistor or synchronized to an external clock. OPTI-LOOP? compensation allows the transient response to be optimized over a wide range of loads and output capacitors.
The LTC3603 can be configured for either Burst Mode operation or forced continuous operation. Forced continuous operation reduces noise and RF interference, while Burst Mode operation provides the highest efficiency at light loads. In Burst Mode operation, external control of the burst clamp level allows the output voltage ripple to be adjusted according to the requirements of the application.
Among them if you have any need quote or problem, please could you tell us.
E-mail: abel.huang911@gamil.com
MSN:abel.huang@hotmail.com
Features
Wide Input Voltage Range: 4.5V to 15V
2.5A Output Current
Low RDS(ON) Internal Switches: 45mΩ and 85mΩ
Programmable Frequency: 300kHz to 3MHz
Low Quiescent Current: 75μA
0.6V ±1% Reference Allows Precise,
Low Output Voltage
99% Maximum Duty Cycle
Adjustable Burst Mode? Clamp
Synchronizable to External Clock
Power Good Output Voltage Monitor
Overtemperature Protection
Overvoltage Protection
Available in 16-Lead Thermally Enhanced MSOP and 4mm × 4mm QFN Packages
MSOP16
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LTC3603IMSE#TRPBF |
|
IC REG BUCK SYNC ADJ 2.5A 16MSOP |
Data Sheet |
|
|
||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||
 |
LTC3025 |
Other |
|
Data Sheet |
Negotiable |
|
||||||
 |
LTC3025EDC#TR |
|
IC REG LDO ADJ .3A 6DFN |
Data Sheet |
|
|
||||||
|
LTC3025EDC#TRM |
|
IC REG LDO ADJ .3A 6DFN |
Data Sheet |
|
|
||||||
|
LTC3025EDC#TRMPBF |
|
IC REG LDO ADJ .3A 6DFN |
Data Sheet |
|
|
||||||
|
LTC3025EDC#TRPBF |
|
IC REG LDO ADJ .3A 6DFN |
Data Sheet |
|
|
||||||
|
LTC3025EDC-1#TRMPBF |
|
IC REG LDO ADJ .5A 6DFN |
Data Sheet |
|
|
||||||
