Product Summary
The LTC3858EGN-1#PBF is a dual 2-phase synchronous step-down controller. Its applications include automotive systems, battery operated digital devices.
Parametrics
LTC3858EGN-1#PBF absolute maximum ratings: (1)Input supply voltage: -0.3 to 40V; (2)Topside driver voltage: -0.3 to 46V; (3)Switch voltage: -5 to 40V; (4)Operating junction temperature range: -40 to 125℃.
Features
LTC3858EGN-1#PBF features: (1)Low operating IQ: 170μA; (2)Wide output voltage range: 0.8V≤VOUT≤24V; (3)Wide VIN range: 4 to 38V; (4)RSENSE or DCR current sensing; (5)Out-of-phase controllers reduce required input capacitance and power supply induced noise.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LTC3858EGN-1#PBF |
|
IC REG CTRLR BUCK PWM CM 28-SSOP |
Data Sheet |
|
|
||||||||||
