Product Summary

The LTC6247CMS8#PBF is a Power Efficient Rail-to-Rail I/O Op Amp. The LTC6247CMS8#PBF family maintains high efficiency performance from supply voltage levels of 2.5V to 5.25V and is fully specified at supplies of 2.7V and 5.0V. For applications that require power-down, the LTC6247CMS8#PBF in MS10 offer a shutdown pin which disables the amplifier and reduces current consumption to 42μA. The applications of the LTC6247CMS8#PBF include Low Voltage, High Frequency Signal Processing, Driving A/D Converters, Rail-to-Rail Buffer Amplifiers, Active Filters, Video Amplifiers, Fast Current Sensing Amplifiers and Battery Powered Equipment.

Parametrics

LTC6247CMS8#PBF absolute maximum ratings: (1)Total Supply Voltage (V+ to V–): 5.5V; (2)Input Current (+IN, –IN, SHDN) (Note 2): ±10mA; (3)Output Current (Note 3): ±100mA; (4)Operating Temperature Range (Note 4): –40℃ to 125℃; (5)Specified Temperature Range (Note 5): –40℃ to 125℃; (6)Storage Temperature Range: –65℃ to 150℃; (7)Junction Temperature: 150℃; (8)Lead Temperature (Soldering, 10 sec) (MSOP, TSOT Packages Only): 300℃.

Features

LTC6247CMS8#PBF features: (1)Gain Bandwidth Product: 180MHz; (2)–3dB Frequency (AV = 1): 120MHz; (3)Low Quiescent Current: 1mA Max; (4)High Slew Rate: 90V/μs; (5)Input Common Mode Range Includes Both Rails; (6)Output Swings Rail-to-Rail; (7)Power-Down Mode: 42μA; (8)Fast Output Recovery; (9)Supply Voltage Range: 2.5V to 5.25V; (10)Input Offset Voltage: 0.5mV Max; (11)Input Bias Current: 100nA; (12)Large Output Current: 50mA; (13)CMRR: 110dB; (14)Open Loop Gain: 45V/mV; (15)Operating Temperature Range: –40°C to 125°C; (16)Single in 6-Pin TSOT-23; (17)Dual in MS8, 2mm × 2mm Thin DFN,TS0T-23, MS10; (18)Quad in MS16.
