Product Summary

The MAX3323EEUE+ is an ESD-protected, RS-232 transceiver for multidrop applications. Its applications include Bar-code scanners, video security, industrial data acquisition, data splitters.

Parametrics

MAX3323EEUE+ absolute maximum ratings: (1)VCC, VL: -0.3 to 6V; (2)Input voltage: ±25V; (3)Output voltage: ±13.2V; (4)Continuous power dissipation: 842mW; (5)Operating temperature range: -40 to 85℃; (6)Junction temperature: 150℃; (7)Storage temperature range: -65 to 150℃; (8)Lead temperature: 300℃.

Features

MAX3323EEUE+ features: (1)pin-selectable 5kΩ/high-impedance receivers; (2)Transmitter outputs three-stated by logic control; (3)VL pin for compatibility with mixed voltage systems; (4)250kbps data rate; (5)1μA low-power shutdown.

Diagrams

MAX3323EEUE+ pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MAX3323EEUE+
MAX3323EEUE+

Maxim Integrated Products

RS-232 Interface IC Transceiver For Multidrop Aps

Data Sheet

0-1: $3.56
1-25: $2.38
25-50: $1.72
50-100: $1.72
