Product Summary

The MAX4052ACSE+T is a CMOS Analog Multiplexer/Switch. The applications of the MAX4052ACSE+T include Battery-Operated Equipment, Audio and Video Signal Routing, Low-Voltage Data-Acquisition Systems and Communications Circuits.

Parametrics

MAX4052ACSE+T absolute maximum ratings: (1)Voltages Referenced to GND V+: -0.3V to +17V; (2)V-: +0.3V to -17V; (3)V+ to V-: -0.3V to +17V; (4)Voltage into Any Terminal (Note 1): (V- - 2V) to (V+ + 2V) or 30mA (whichever occurs first); (5)Continuous Current into Any Terminal: ±30mA; (6)Peak Current, NO or COM (pulsed at 1ms, 10% duty cycle): ±100mA; (7)Continuous Power Dissipation (TA = +70℃) Plastic DIP (derate 10.53mW/℃ above +70℃): 842mW; (8)Narrow SO (derate 8.70mW/℃ above +70℃): 696mW; (9)QSOP (derate 8.00mW/℃ above +70℃): 640mW; (10)CERDIP (derate 10.00mW/℃ above +70℃): 800mW; (11)Operating Temperature Ranges: 0℃ to +70℃; (12)Storage Temperature Range: -65℃ to +150℃; (13)Lead Temperature (soldering, 10sec): +300℃.

Features

MAX4052ACSE+T features: (1)Single-Supply Operation from +2.0V to +16V Dual-Supply Operation from ±2.7V to ±8V; (2)TTL/CMOS-Logic Compatible; (3)Low Distortion: < 0.04% (600Ω); (4)Low Crosstalk: < -90dB (50Ω); (5)High Off Isolation: < -90dB (50Ω).

Diagrams

MAX4052ACSE+T dimension

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MAX4052ACSE+T
MAX4052ACSE+T

Maxim Integrated Products

Multiplexer Switch ICs 4:1 2Ch Low Voltage Analog MUX

Data Sheet

0-2080: $1.19
2080-2500: $1.19
