Product Summary
The MAX4514ESA+T is a low-voltage, low-on-resistance, SPST, CMOS analog switch. Its applications include battery-operated equipment, audio and video signal routing, low-voltage data-acquisition systems, communications circuits, PCMCIA cards, cellular phones, modems.
Parametrics
MAX4514ESA+T absolute maximum ratings: (1)Voltages referenced to GND: -0.3 to 13V; (2)Voltage into any terminal: -0.3 to V+0.3V; (3)Continuous current into any terminal: ±20mA; (4)Peak current, NO_or COM_: ±30mA; (5)ESD per method: >2000V; (6)Continuous power dissipation: 727mW; (7)Operating temperature ranges: -40 to 85℃; (8)Storage temperature range: -65 to 150℃; (9)Lead temperature: 300℃.
Features
MAX4514ESA+T features: (1)Available in SOT23-5 package; (2)+2V to 12V single-supply operation; (3)Guaranteed on-resistance: 20Ω with +5V supply; (4)Guaranteed low off-leakage current: 1nA at 25℃; (5)Guaranteed low on-leakage currents: 2nA at 25℃; (6)Low charge injection: 10pC; (7)Fast switching speed: tON=150ns, tOFF=100ns; (8)Break-before-make operation; (9)TTL/CMOS-logic compatible with 5V supply.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 MAX4514ESA+T |
Maxim Integrated Products |
Analog Switch ICs SPST CMOS Analog Switch |
Data Sheet |
|
|
||||||||||||
