Product Summary
The HCPL-2631-500E is a high speed logic gate optocoupler. Its applications include ground loop elimination, line receiver, data transmission, data multiplexing, swtiching power supplies, pulse transformer replacement.
Parametrics
HCPL-2631-500E absolute maximum ratings: (1)Storage temperature, Tstg: -55 to 125℃; (2)Operating temperature, TOPR: -40 to 85℃; (3)Lead solder temperature, TSOL: 260℃; (4)Input current, IF: 30mA; (5)Enable input voltage, VE: 5.5V; (6)Supply voltage, VCC: 7V; (7)Output current: 50mA.
Features
HCPL-2631-500E features: (1)very high speed-10 MBit/s; (2)superior CMR-10 kV/μs; (3)double working voltage-480V; (4)Fan-out of 8 over -40 to 85℃; (5)Logic gate output; (6)Strobable output; (7)Wired OR-open collector.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 HCPL-2631-500E |
Avago Technologies |
High Speed Optocouplers 10MBd 2Ch 5mA |
Data Sheet |
|
|
||||||||||||
