Product Summary

The LM324DR2G is a single supply quad operational amplifier.

Parametrics

LM324DR2G absolute maximum rating: (1)Power supply volatge, single supply, VCC: 32Vdc; Split supplies, VCC, VEE: ±16Vdc; (3)Input differential voltage range, VIDR: ±32Vdc; (4)Input common mode voltage range, VICR: -0.3 to 32Vdc; (5)Output short circuit duration, tSC: continuous; (6)Junction temperature, TJ: 150℃; (7)Storage temperature range, Tstg: -65 to 150℃.

Features

LM324DR2G features: (1)Short circuited protected outputs; (2)True differential stage; (3)Single supply opreration; (4)Low input bias currents; (5)Four amplifiers per package; (6)Internally compensated; (7)Common mode range extends to negative supply; (8)Industry standard pinouts.

Diagrams

LM324DR2G pin connections

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
LM324DR2G
LM324DR2G

ON Semiconductor

Operational Amplifiers - Op Amps 3-32V Quad 5mV VIO Commercial Temp

Data Sheet

0-1: $0.28
1-25: $0.19
25-100: $0.15
100-500: $0.10
