Product Summary
The LT4180 solves the problem of providing tight load regulation over long, highly resistive cables without requiring an additional pair of remote sense wires. This Virtual Remote Sense device continuously interrogates the line impedance and corrects the power supply output voltage via its feedback loop to maintain a steady voltage at the load regardless of current changes.
The LT4180 is a full-featured controller with 5mA optoisolator sink capability, under/overvoltage lockout, soft-start and a ±1% internal voltage reference. The Virtual Remote Sense feature set includes user-programmable dither frequency and optional spread spectrum dither.
The LT4180 works with any topology and type of isolated or nonisolated power supply, including DC/DC converters and adjustable linear regulators.
The LT4180 is available in a 24-pin, SSOP package.
Features
Tight Load Regulation with Highly Resistive Cables without Requiring Remote Sense Wiring
Compatible with Isolated and Nonisolated Power Supplies
±1% Internal Voltage Reference
5mA Sink Current Capability
Soft-Correct Reduces Turn-On Transients
Undervoltage and Overvoltage Protection
Pin-Programmable Dither Frequency
Optional Spread Spectrum Dither
Wide VIN Range: 3.1V to 50V
24-Pin SSOP Package
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LT4180EGN#PBF |
|
IC PWR SUPPLY CONTROLLER 24SSOP |
Data Sheet |
|
|
||||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||||
|
LT4180EGN#PBF |
|
IC PWR SUPPLY CONTROLLER 24SSOP |
Data Sheet |
|
|
||||||||||
|
LT4180EGN#TRPBF |
|
IC CTLR REMOTE SENSOR 24SSOP |
Data Sheet |
|
|
||||||||||
|
LT4180IGN#PBF |
|
IC PWR SUPPLY CONTROLLER 24SSOP |
Data Sheet |
|
|
||||||||||
|
LT4180IGN#TRPBF |
|
IC CTLR REMOTE SENSOR 24SSOP |
Data Sheet |
|
|
||||||||||
|
LT4180MPGN#PBF |
|
IC PWR SUPPLY CONTROLLER 24SSOP |
Data Sheet |
|
|
||||||||||
|
LT4180MPGN#TRPBF |
|
IC CTLR REMOTE SENSOR 24SSOP |
Data Sheet |
|
|
||||||||||
