Product Summary
The LTC3862EGN-1#PBF is a Multi-Phase Current Mode Step-Up DC/DC Controller. Its applications include automotive, telecom and industrial power supplies.
Parametrics
LTC3862EGN-1#PBF absolute maximum ratings: (1)Input supply voltage: -0.3 to 40V; (2)INTVCC voltage: -0.3 to 11V; (3)RUN Voltage: -0.3 to 6V; (4)Operating junction temperature range: -40 to 125℃; (5)Storage temperature range: -65 to 150℃; (6)Reflow peak body temperature: 260℃.
Features
LTC3862EGN-1#PBF features: (1)Wide vin range: 8.5 to 36V operation; (2)2-phase operation reduces input and output capacitance; (3)Fixed frequency, peak current mode control; (4)10V gate drive for high voltage MOSFETs; (5)Adjustable slope compensation gain.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LTC3862EGN-1#PBF |
|
IC REG CTRLR BST PWM CM 24-SSOP |
Data Sheet |
|
|
||||||
